Puritech Ultraflow-F High Flow Filter Cartridges

Puritech Ultraflow-F High Flow Filter Cartridge is a solution for lowering capital cost and operation cost with the benefits of longer service life and less request quantity. With Puritech unique U-pleat style and multi-layer structure, Ultraflow-F have excellent filtration area and removal efficiency. Large diameter is suitable for high flow and large volume applications.

Features and Benefits:

  • Imported polypropylene membrane with high porosity and excellent removal efficiency
  • Multi-layer structure provides higher dirt holding capacity and longer service life
  • Unique U-pleat technology provides good integrity and larger filtration area
  • Diameter 6 “(152 mm) is suitable for large flow and high-volume applications


  • Filter Medium:        Polypropylene Depth Membrane
  • Inner Core:            Reinforced Polypropylene
  • End caps:              Reinforced Polypropylene
  • O-rings:                EPDM / NBR
  • Construction Method: Welding (No adhesives)


  • Body Diameter:        6” (152.4 mm)
  • Connector Diameter:  4.4” (113 mm)
  • Micron Rating:        1μm, 3μm, 5μm,10μm, 30μm, 50μm, 70μm, 100μm, 120μm,150μm
  • Length:               20”, 40”, 60”, 80”

Recommended operation condition:

  • Maximum Temperature:   80 ℃
  • Maximum Pressure:         2.8 bar@60 ℃
  • Recommended Change-out Differential Pressure:   2.4 bar @20 ℃

Typical Application:

  • RO pre-filtration
  • Municipal water
  • Boiler Condensate
  • Process water (Food & Beverage, Electronics, Pharmaceuticals)
